C#を使ったデジタル時計の作成の仕方について徹底解説!

- システム
エンジニア - デジタル時計の作成に興味があります。
- プロジェクト
マネージャー - C#だと簡単に作成できますよ。実際のソースコードを参考に見ていきましょう。
C#の時計について
今回は、C#の時計についてご説明していきます。
TimerクラスのTickイベントを利用すれば、簡単にデジタル時計を作成することができます。C#の時計に興味のある方は、ぜひ参考にしてみてはいかがでしょうか。
デジタル時計
ここでは、C#を使ったデジタル時計の作成方法をご紹介していきます。
時刻表示機能、時刻設定機能、アラーム機能について、順番に解説していきますので、機能を応用して、自分なりに拡張してみましょう。
時刻表示機能
C#で、TimerクラスのTickイベントを利用して、時刻表示機能があるデジタル時計を作成してみます。
実際のソースコードを見てみましょう。
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 |
using System; using System.Drawing; using System.Windows.Forms; namespace WindowsFormsApp1 { public partial class Form1 : Form { Timer timer; Label timeLabel; DateTime dt; public Form1() { InitializeComponent(); this.Text = "デジタル時計"; this.Size = new Size(300, 300); this.Load += Form1_Load; } private void Form1_Load(object sender, EventArgs e) { timeLabel = new Label(); timeLabel.Location = new Point(10, 10); timeLabel.AutoSize = true; dt = DateTime.Now; timeLabel.Text = string.Format("日時\r\n{0:0000}/{1:00}/{2:00} {3:00}:{4:00}:{5:00}", dt.Year, dt.Month, dt.Day, dt.Hour, dt.Minute, dt.Second); // timerの設定 timer = new Timer(); timer.Interval = 1000; timer.Enabled = true; timer.Tick += Timer_Tick; this.Controls.Add(timeLabel); } // 1秒周期のtimerイベント private void Timer_Tick(object sender, EventArgs e) { dt = DateTime.Now; timeLabel.Text = string.Format("日時\r\n{0:0000}/{1:00}/{2:00} {3:00}:{4:00}:{5:00}", dt.Year, dt.Month, dt.Day, dt.Hour, dt.Minute, dt.Second); } } } |
1000ミリ秒(1秒)周期のtimerイベントで現在時刻を取得し、labelを更新しています。
1秒ごとに、時刻が更新されることが分かります。
このように、C#で、TimerクラスのTickイベントを利用してデジタル時計を作成できます。
時刻設定機能
先ほどのサンプルでは、現在時刻を表示するだけでしたが、これを応用して、C#で時刻設定機能を実装してみます。
実際のソースコードを見てみましょう。
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 |
using System; using System.Drawing; using System.Windows.Forms; namespace WindowsFormsApp1 { public partial class Form1 : Form { Timer timer; Label timeLabel; DateTime dt; Button timeChangeButton, timeChangeOKButton; Form timeChangeForm; DateTimePicker dateTimePicker1; TimeSpan timeSpan; public Form1() { InitializeComponent(); this.Text = "デジタル時計"; this.Size = new Size(300, 300); this.Load += Form1_Load; } private void Form1_Load(object sender, EventArgs e) { timeLabel = new Label(); timeLabel.Location = new Point(10, 10); timeLabel.AutoSize = true; dt = DateTime.Now; timeLabel.Text = string.Format("日時\r\n{0:0000}/{1:00}/{2:00} {3:00}:{4:00}:{5:00}", dt.Year, dt.Month, dt.Day, dt.Hour, dt.Minute, dt.Second); timer = new Timer(); timer.Interval = 1000; timer.Enabled = true; timer.Tick += Timer_Tick; timeChangeButton = new Button(); timeChangeButton.Location = new Point(10, 40); timeChangeButton.Text = "時刻設定"; timeChangeButton.Click += TimeChangeButton_Click; // 時刻加算用のTimeSpan timeSpan = new TimeSpan(0, 0, 0, 1); // 時刻設定Form ///////////////////////// timeChangeForm = new Form(); timeChangeForm.Text = "時刻設定"; dateTimePicker1 = new DateTimePicker(); dateTimePicker1.Location = new Point(10, 10); dateTimePicker1.Format = DateTimePickerFormat.Custom; dateTimePicker1.CustomFormat = "yyyy/MM/dd HH:mm:ss"; timeChangeForm.Controls.Add(dateTimePicker1); timeChangeOKButton = new Button(); timeChangeOKButton.Location = new Point(10, 40); timeChangeOKButton.Text = "OK"; timeChangeOKButton.Click += TimeChangeOKButton_Click; timeChangeForm.Controls.Add(timeChangeOKButton); //////////////////////////////////////// this.Controls.Add(timeLabel); this.Controls.Add(timeChangeButton); } private void TimeChangeButton_Click(object sender, EventArgs e) { if (timeChangeForm.ShowDialog(this) == DialogResult.OK) { dt = dateTimePicker1.Value; timeLabel.Text = string.Format("日時\r\n{0:0000}/{1:00}/{2:00} {3:00}:{4:00}:{5:00}", dt.Year, dt.Month, dt.Day, dt.Hour, dt.Minute, dt.Second); } } private void TimeChangeOKButton_Click(object sender, EventArgs e) { timeChangeForm.DialogResult = DialogResult.OK; timeChangeForm.Close(); } private void Timer_Tick(object sender, EventArgs e) { // 1秒加算する dt = dt.Add(timeSpan); timeLabel.Text = string.Format("日時\r\n{0:0000}/{1:00}/{2:00} {3:00}:{4:00}:{5:00}", dt.Year, dt.Month, dt.Day, dt.Hour, dt.Minute, dt.Second); } } } |
“時刻設定”ボタンをクリックすると、時刻設定Formが開きます。
DateTimePickerクラスで時刻を設定し、OKボタンをクリックすると、設定した日時でデジタル時計が更新されます。
日時を自由に変更してみてください。変更後に、timerイベントで1秒ごとに1秒加算されることが分かります。
このように、C#で時刻設定機能を実装できます。
アラーム機能
先ほどのサンプルに、アラーム機能を実装してみます。
実際のソースコードを見てみましょう。
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170 171 172 173 174 175 176 177 178 179 180 181 182 183 |
using System; using System.Drawing; using System.Windows.Forms; namespace WindowsFormsApp1 { public partial class Form1 : Form { Timer timer; Label timeLabel, alarmLabel; DateTime dt, alarmDt; Button timeChangeButton, timeChangeOKButton, alarmSetButton, alarmSetOKButton, alarmStopButton; Form timeChangeForm, alarmSetForm; DateTimePicker dateTimePicker1, dateTimePicker2; TimeSpan timeSpan; Boolean isAlarmSet, isAlarmStop; public Form1() { InitializeComponent(); this.Text = "デジタル時計"; this.Size = new Size(300, 300); this.Load += Form1_Load; } private void Form1_Load(object sender, EventArgs e) { timeLabel = new Label(); timeLabel.Location = new Point(10, 10); timeLabel.AutoSize = true; dt = DateTime.Now; timeLabel.Text = string.Format("日時\r\n{0:0000}/{1:00}/{2:00} {3:00}:{4:00}:{5:00}", dt.Year, dt.Month, dt.Day, dt.Hour, dt.Minute, dt.Second); alarmLabel = new Label(); alarmLabel.Location = new Point(150, 10); alarmLabel.AutoSize = true; alarmLabel.Visible = false; timer = new Timer(); timer.Interval = 1000; timer.Enabled = true; timer.Tick += Timer_Tick; timeChangeButton = new Button(); timeChangeButton.Location = new Point(10, 40); timeChangeButton.Text = "時刻設定"; timeChangeButton.Click += TimeChangeButton_Click; alarmSetButton = new Button(); alarmSetButton.Location = new Point(100, 40); alarmSetButton.Text = "アラーム設定"; alarmSetButton.Click += AlarmSetButton_Click; alarmStopButton = new Button(); alarmStopButton.Location = new Point(190, 40); alarmStopButton.Text = "アラーム停止"; alarmStopButton.Visible = false; alarmStopButton.Click += AlarmStopButton_Click; timeSpan = new TimeSpan(0, 0, 0, 1); isAlarmSet = false; isAlarmStop = false; // 時刻設定Form ///////////////////////// timeChangeForm = new Form(); timeChangeForm.Text = "時刻設定"; dateTimePicker1 = new DateTimePicker(); dateTimePicker1.Location = new Point(10, 10); dateTimePicker1.Format = DateTimePickerFormat.Custom; dateTimePicker1.CustomFormat = "yyyy/MM/dd HH:mm:ss"; timeChangeForm.Controls.Add(dateTimePicker1); timeChangeOKButton = new Button(); timeChangeOKButton.Location = new Point(10, 40); timeChangeOKButton.Text = "OK"; timeChangeOKButton.Click += TimeChangeOKButton_Click; timeChangeForm.Controls.Add(timeChangeOKButton); //////////////////////////////////////// // アラーム設定Form //////////////////// alarmSetForm = new Form(); alarmSetForm.Text = "アラーム設定"; dateTimePicker2 = new DateTimePicker(); dateTimePicker2.Location = new Point(10, 10); dateTimePicker2.Format = DateTimePickerFormat.Custom; dateTimePicker2.CustomFormat = "yyyy/MM/dd HH:mm:ss"; alarmSetForm.Controls.Add(dateTimePicker2); alarmSetOKButton = new Button(); alarmSetOKButton.Location = new Point(10, 40); alarmSetOKButton.Text = "OK"; alarmSetOKButton.Click += AlarmSetOKButton_Click; alarmSetForm.Controls.Add(alarmSetOKButton); //////////////////////////////////////// this.Controls.Add(timeLabel); this.Controls.Add(alarmLabel); this.Controls.Add(timeChangeButton); this.Controls.Add(alarmSetButton); this.Controls.Add(alarmStopButton); } private void TimeChangeButton_Click(object sender, EventArgs e) { if (timeChangeForm.ShowDialog(this) == DialogResult.OK) { dt = dateTimePicker1.Value; timeLabel.Text = string.Format("日時\r\n{0:0000}/{1:00}/{2:00} {3:00}:{4:00}:{5:00}", dt.Year, dt.Month, dt.Day, dt.Hour, dt.Minute, dt.Second); } } private void TimeChangeOKButton_Click(object sender, EventArgs e) { timeChangeForm.DialogResult = DialogResult.OK; timeChangeForm.Close(); } private void AlarmSetButton_Click(object sender, EventArgs e) { if (alarmSetForm.ShowDialog(this) == DialogResult.OK) { alarmDt = dateTimePicker2.Value; isAlarmSet = true; isAlarmStop = false; alarmLabel.Text = string.Format("アラーム\r\n{0:0000}/{1:00}/{2:00} {3:00}:{4:00}:{5:00}", alarmDt.Year, alarmDt.Month, alarmDt.Day, alarmDt.Hour, alarmDt.Minute, alarmDt.Second); alarmLabel.Visible = true; } } private void AlarmSetOKButton_Click(object sender, EventArgs e) { alarmSetForm.DialogResult = DialogResult.OK; alarmSetForm.Close(); } private void AlarmStopButton_Click(object sender, EventArgs e) { isAlarmStop = true; alarmLabel.Visible = false; alarmStopButton.Visible = false; Console.WriteLine("alarm stopped"); } private void Timer_Tick(object sender, EventArgs e) { dt = dt.Add(timeSpan); timeLabel.Text = string.Format("日時\r\n{0:0000}/{1:00}/{2:00} {3:00}:{4:00}:{5:00}", dt.Year, dt.Month, dt.Day, dt.Hour, dt.Minute, dt.Second); if (isAlarmSet && dt >= alarmDt && !isAlarmStop) { Console.WriteLine("alarm!!!!"); alarmStopButton.Visible = true; } else { alarmStopButton.Visible = false; } } } } |
“アラーム設定”ボタンをクリックすると、アラーム設定画面が開き、アラームを設定すると、アラーム設定時刻がデジタル時計に表示されます。
アラームの時間を過ぎると、アラームが発生します。
サンプルプログラムでは、コンソールに”alarm!!!!”が表示されます。
“アラーム停止”ボタンをクリックすると、標準出力が停止されます。このように、C#でアラーム機能を実装できます。
- システム
エンジニア - アラーム機能が実装できたり、いろいろカスタマイズできそうですね。
- プロジェクト
マネージャー - 興味が深まったようで何よりです。是非実際に作成してみてください。
C#を使ってデジタル時計を作成してみよう
いかがでしたでしょうか。C#では、TimerクラスのTickイベントを利用すれば、簡単にデジタル時計を作成できます。ここで紹介した機能を応用して、自分なりに拡張してみましょう。
今回はデジタル時計を紹介しましたが、長針や短針を描画すればアナログ時計も作成できます。ぜひご自身でC#のソースコードを書いて、理解を深めていきましょう。
